Heatmap exploration#

The Heatmap tab in the Results Viewer pivots (Grid_RowNum, Grid_ColNum) into a plate-shaped Plotly heatmap. Coloring is driven by any measurement column — or, when QC checks are configured, by any QC_*_Severity column the QC tab emits into the augmented frame — so the same surface doubles as a quick-look quality dashboard.

The exploration loop:

  1. Pick a color column (e.g. Size_Area, Shape_Circularity, or a QC_*_Severity column).

  2. Pick an image from the dropdown.

  3. If multi-timepoint data is present, sweep the time slider to watch the colour pattern evolve.

  4. Spot edge effects, contamination patches, or replicate-level anomalies at a glance — then curate the offending cells from the Plate / Colony tabs and watch the × overlay appear on the same heatmap.

Prerequisites#

  • A CLI run that emitted Grid_RowNum / Grid_ColNum columns into deliverables/measurements.parquet (i.e. a GridFinder-aware pipeline). The empty-state placeholder is rendered when these columns are absent.

  • Optionally, one or more configured QC checks (see QC curation loop) so the color picker surfaces QC_*_Severity columns.

Walkthrough#

Open the Viewer tab in the hub and pick the Heatmap sub-tab:

Heatmap tab on first open showing empty-state explanation.

When Grid_RowNum / Grid_ColNum are absent from the filtered frame (as is the case for the synthetic tutorial dataset, which uses a non-grid pipeline) the tab renders an explanation card pointing at GridMeasureFeatures. No exceptions, no blank figure — the empty state is a first-class affordance.

On a real grid-aware run, the top strip shows four controls:

  • Color column: dropdown listing every measurement column in the schema plus any QC_*_Severity columns currently emitted (recipe-revision-aware — adding a QC check at runtime adds its severity column to the dropdown).

  • Aggregator: mean / median / max / min. Aggregation fires after the image-file filter, so it only matters when more than one row shares a (Grid_RowNum, Grid_ColNum, Metadata_Time) bin.

  • Image: the source image whose colonies are pivoted.

  • Time: slider with marks at every unique numeric Metadata_Time value. Hidden when only one timepoint exists, when the column is absent, or when coercion to numeric yields all-NaN.

Color picker dropdown open showing the union of measurement and QC severity columns.

The heatmap renders below the strip. Hover labels carry (row, col) — value — ImageFile — Object_Label. Curated cells — those tracked in STORE_REMOVED_KEYS — render as COLOR_MUTED × markers on a secondary go.Scatter trace, visually distinct from genuinely low-value cells in the colormap.

Common gotchas#

  • Empty state vs. NaN cells: the empty-state card fires only when the grid columns are absent from the schema. If they’re present but every cell in the current (image, time) slice is NaN, the heatmap still renders — just with no coloured cells. Switch the time slider or aggregator to surface valid bins.

  • Non-numeric time values: if Metadata_Time carries strings like "T0" / "baseline", pd.to_numeric(..., errors="coerce") drops those rows and a small caption (skipping N non-numeric time values) appears below the slider. Coerce upstream in your metadata if you want every row to participate.

  • Aggregator semantics: for the typical one-row-per-well case flipping aggregator is a no-op. It only changes the picture when the pipeline emits multiple rows per well (e.g. multi-object detection without GridMeasureFeatures’s per-cell collapse).

Where to next#

  • QC curation loop — produce QC_*_Severity columns so the heatmap can colour by quality instead of raw measurements.

  • View Results — curate flagged cells from the Plate / Colony tabs; the × overlay updates in lockstep.

  • Analysis — fit a model against the cleaned measurements.
